QUALITY BRASS BALL VALVES FOR YOUR INDUSTRY

Ragco full port forged brass ball valves are suitable for a full range of fluids and gases (including gasoline & diesel), and allow for minimal pressure drop due to their large port size. The quick quarter-turn function requires low operating torque. Each individual valve is tested and has an adjustable packing gland for the blowout proof stem. Our ball valves meet specifications for various industrial approvals including UL842, UL258, UL125, FM, and more.



Brass Ball Valve
2 Piece • Full Port • Threaded Connection • 600 WOG

Features

  • Gland follower and single o-ring stem design

  • Blow-out proof stem

  • 100% leak tested

Approvals

  • UL Listed up to 175 PSI (1/4” - 2”)

    • MHKZ - Manual valves

    • YRPV - Gas shutoff valves

  • UL Listed up to 250 PSI (1/4” - 4”)

    • YQNZ - Compressed gas shutoff valves

    • YRBX - Flammable liquid shutoff valves

    • YSDT - LP gas shutoff valves

  • CSA Certified

    • CGA 3.16 (125 PSIG)

    • ANSI Z21.15 (.5 PSIG)

    • CGA CR91 (5 PSIG)

    • ASME B16.44 (5 PSIG)

    • ASME B16.33 (125 PSIG) (1/2” - 2”)

    • ASME B16.38 (125 PSIG) (2-1/2” - 4”)

  • FM Approval (1/4” - 2”)

  • MSS SP-110

  • ANSI B1.20.1


VALVE SEAT RATING
600 WOG - 150 WSP






WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and lead, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
